Purpose
Engineered for low-temperature environments, this rack optimizes storage and management of frozen foods, fresh refrigerated goods, and quick-frozen products in cold rooms. Featuring stable construction and corrosion resistance, it enables multi-tier stacking with forklifts to maximize cold storage density while ensuring operational safety.
Application Fields
Cold Chain Logistics:
Storage and transit of frozen/quick-frozen foods, seafood, meat, fruits, and eggs.
01
Food Processing Plants:
Long-term storage of seasonal ingredients (e.g., frozen produce).
02
Fresh E-commerce:
Sorting, buffering, and pre-distribution management.
03
Supermarket Cold Rooms:
Vertical storage for high-turnover goods.
04
3PL Services:
Flexible solutions for leased or retrofitted cold storage facilities.
05
Specifications, Material & Technical Parameters
|
Item |
Specification/Material Description |
|
Main Material |
Q235B Steel (50×50×2.0mm square tube columns; 50×50×1.5mm base tubes; reinforced with 50×3.0t angle steel) |
|
Surface Treatment |
Hot-dip galvanizing or electrostatic spray coating (≥60μm), low-temp/corrosion-resistant |
|
Standard Dimensions |
1320×1250×1600mm (Customizable) |
|
Load Capacity |
Dynamic load: ≥1500kg/tier; Static load: ≥6T total |
|
Stacking Height |
3-4 tiers (Max. height: 8m) |
|
Operating Temp. |
-25°C to ambient (Cold room optimized) |
Product Features
1.Cryogenic Adaptation
Hot-dip galvanizing/high-adhesion spray coating resists humidity and rust in prolonged sub-zero conditions.
2.Seismic Stability
90°/82° interlocking angle steel design enhances stability under load (ideal for seismic zones).
3.Space Optimization
3-4 tier stacking; nested empty racks occupy 1/3 of single-tier space, tripling storage density.
4.Mobility
Forklift-transportable without disassembly, enabling dynamic storage reconfiguration.
5.Structural Longevity
Full-welded construction with 18-grid reinforced base ensures even load distribution (10+ year lifespan).
Target Customer Groups
Cold chain logistics providers and 3PL cold storage operators.
01
Food processors, fresh e-commerce platforms, and hypermarkets.
02
High-density cold storage users (frozen/refrigerated goods).
03
Retrofit projects for leased or aging warehouses.
04
Overview
This rack elevates cold storage efficiency and safety through heavy-load capacity, high-density stacking, and operational flexibility. Customizable to client specifications, with factory audits and sample testing supported.
